Box Blade

$775.00
$970.00
$775.00

A box blade is a versatile attachment for tractors, designed to level, grade, and move soil, gravel, or other materials.

Availability: Will be in stock within 10/31/2026
Buy Now, Pay Later Flexible payment options available
Need Help With Your Order? Call or Text: +1 (302) 405-3306
Working Size: 4'
map
Box Blade

Box Blade

$970.00 $775.00
Box Blade
Box Blade
Box Blade
Box Blade
Box Blade

Box Blade

$970.00 $775.00
Working Size: 4'
    Overview

    Longhorn box blade is a powerful and multifunctional tool used in landscaping, construction, and agriculture. It consists of a rectangular, enclosed frame with multiple adjustable scarifier blades at the front and a rear blade or cutting edge. Box blades are commonly used for tasks such as grading roads, maintaining driveways, leveling soil for planting, and spreading gravel. Their design allows for precise control over soil distribution and leveling, making them ideal for a wide range of earth-moving applications.

    Specifications

    Specification LHBBSD-4 LHBBMD-5 LHBBMD-6 LHBBMD-7
    Overall Length2 ft. 3"
    Overall Width 4 ft. 1" 5 ft. 1" 6 ft. 1" 7 ft. 1"
    Working Width 4 ft. 5 ft. 6 ft. 7 ft.
    Box Height1 ft. 5"
    Frame Tube Size4" x 4" x 0.31"
    End Plate Thickness 0.39" 0.47"
    Mould Board Thickness 0.20" 0.24"
    Number of Scarifiers 4 5 6 7
    Cutting Blade (Size & Qty.)6" x 0.39", High Carbon Steel, Reversible (2)
    Hitch CAT-1 CAT-1 & CAT-2
    Quick Hitch Compatible Yes Yes
    Weight (with Scarifier) (Lbs.) Weight Icon 448 552 621 684
    Weight (without Scarifier) (Lbs.) Weight Icon 408 496 555 610
    Tractor (HP) Tractor Icon 30-45 45-60

    FEATURES

    • Suitable for Land leveling, Scraping, Grading & Back filling in small fields, construction sites & building driveways.
    • Reinforced steel Main Frame design for easy attachment and durability.
    • High-strength mouldboards for tackling rugged jobs.
    • Adjustable sacrificer teeth with replaceable tips for durability and versatility.
    • High-carbon reversible/replaceable cutting edges for versatility and a level finish.
    • 4 positions heat treated shanks with replicable tips.
    • Ensure fast, easy and safe hook-ups with ASABE quick-hitch compatibility.
    3 Point linkage

    Sturdy 3 Point Linkage

    Height adjustment

    Front Linkage

    Heavy duty frame assembly

    Height Adjustment

    Heavy duty frame assembly

    Shank Tyne
